Structure: Solid sheet composed of layers of approximately 0.04 to 0.12" veneer of end grain wood and wood with the grain, glued crosswise

Length: Maximum length 96.46", tolerance sawn 0.2 - 0.3 %

Width: maximum width 49.21", tolerance sawn 0.2 - 0.3 %

Thickness: 0.71 to 1.97", tolerance sanded ± 0.01"

Squareness: ± 0.04" per 39.37"

Density: Depending on the kind of wood 400 - 800 kg/m³

Dimension stability: According to NEN-EN 318 measured by the SHR RC 2115 with climate changes
Standard climate 20 ± 2 °C and 65 ± 5 % RH
Dry 20 ± 2 °C and 35 ± 5 % RH
Humid 20 ± 2 °C and 85 ± 5 % RH
Result: Dependent on kind of wood
Lengthwise (direction of the lines) ≤ 0.1 %
Crosswise (width direction, direction square to the lines) ≤ 2 %
Thicknesswise (in the thickness direction) no measurable result

Tensile strength: Measured perpendicularly according NEN-EN 319 by the SHR RC 2115
Bonding of Plexwood ≥ 1.01 N/mm², the glue used by Plexwood meets quality D4 according to NEN-EN 204

Wood properties: Wood is not static, has a high electrical resistance (1 - 1000 MΩ), and a small heat conductivity (0.11 - 0.16 W/m²K) of which the effect is that it slows down the spreading of fire (source: Wood Vademecum; Wood Centre Foundation [Hout Vademecum; Stichting Centrum Hout], Almere 2001, pages 46, 48)

Size conversion: Plexwood uses the metric system in all formal communication. No rights can be derived from size conversions to the imperial system. Plexwood converts sizes for your convenience only
